Inwerter Wyspowy Off-grid / UPS 1000W 12V MPPT 80A

649,59 zł
Dostawa w 24-48h
Indeks: HY1012M

Sprawdzony, przetestowany, Skonfigurowany Inwerter Wyspowy Off-Grid / UPS 1000W 12V MPPT. Gwarancja PL

Wysyłka w 24h

Model No.

HY1012M

Rated power

1000VA /1000W

Input voltage

230VAC

 selectable voltage range

170-280VAC (for personal computers) 90-280VAC (for home appliances)

Frequency range

50Hz/60Hz (auto sensing)

OutputAC voltage regulation (Batt.mode)

230VAC±5%

 Surge power (5 seconds)

2000VA

efficiency (peak)

90%-93%

transfer time

10ms(for personal computers); 20ms (for home appliances)

waveform

pure sine wave

Battery& AC charger

battery voltage

12VDC

floating charge voltage

13.5VDC

overcharge protection

15VDC

maximum charge current

MAX PV array power

900W

maximum PV array open circuit voltage

80VDC

MPPT charging current

80A

maximum efficiency

98%

standby power consumpsion

2W

Dimension, D*W*H(mm)

95*240*316

Net weight (kgs)

5KG

humidity

5%-95% relative humidity ( non-condensing)

operating temperature

0°C -55°C

storage temperature

-15°C -60°C

HY1012M
10 Przedmioty

Specyficzne kody

ean13
5905527993208

Pliki do pobrania

HY1012M DataSheet

Karta Katalogowa

Pliki do pobrania (129.08KB)
